IA2036

30V/ 6A Frequency-ADJ PFM&CCM Step-Down Converter

• Wide 4.0V to 30V Operating Input Range

• 5A Continuous Output Current

• Switching Frequency ADJ

• Short Protection with Hiccup-Mode

• Built-in Over Current Limit

• Integrated internal Soft-Start

• 25/18mΩ Low RDSON Internal MOSFETs

• Output Adjustable from 0.8V

• 100% Duty cycle max

• Thermal Shutdown

• COT Mode
